Casing Pipe



1. Standard: API5L AND API5CT
2.seamless petroleum casing pipe
3. API certificate
4.strong produce capacity
4.NDT & pressure test
Casing Pipe

Grade:
 API 5L : A25,A,B,X42,X46,X52,X56,X60,X65,X70,X80
 API 5CT: J55 K 55 M65 N80 L 80 C 90 T 95 P110 H40  Q125 CS-90 SCS-95 SCS-80 TCS-110T

Other steel grade is available as per clients requirements.
Specifications:
O.D.89-820mm, W.T. 3- 16mm.
Beveled/plain end or varnished as per clients confirmation
Application:
Generally for conveying gas and oil in both oil and natural gas industries
Casing Pipe
Dimensions, Mechanical properties, Chemical compositions:
Refer to API 5CT or as per clients requirements
keywords:seamless petroleum casing ,petrolem casing pipe,casing pipe



Casing Pipe Features and Benefits :



Casing Pipe

Oil casing and tubing J55, K55, N80, L80, P110

API 5ct

R2/R3 BTC /LTC /STC,
API-5ct Certificate octg casing
Material: API 5 CT J/K 55 casing pipe/J/K 55 N80 P110 L80/oil casing octg casing
casing pipe
R2/R3 length BTC /LTC /STC

OD mm Ib/ft Grade W.T   short   long buttress
114.30(4 1/2") 9.50 H,J,K 5.21 YES
10.50 J,K 5.69 YES   YES
11.60 J,K,C,L,N,P 6.35 YES YES YES
13.50 C,L,N,P 7.37   YES YES
15.10 P,Q 8.56   YES YES
127.00(5") 11.50 J,K 5.59 YES
13.00 J,K 6.43 YES YES YES
15.00 J,K,C,L,N,P 7.52 YES YES YES
18.00 C,L,N,P,Q 9.19   YES YES
21.40 C,L,N,P,Q 11.10   YES YES
23.20 C,L,N,P,Q 12.14   YES YES
24.10 C,L,N,P,Q 12.70   YES YES
139.70(5 1/2") 14.00 H,J,K 6.20 YES
15.50 J,K 6.98 YES YES YES
17.00 J,K,C,L,N,P 7.72 YES YES YES
20.00 C,L,N,P 9.17   YES YES
23.00 C,L,N,P,Q 10.54   YES YES
168.28(6 5/8") 20.00 H,J,K 7.32 YES YES YES
24.00 J,K,C,L,N,P 8.94 YES YES YES
28.00 C,L,N,P 10.59   YES YES
32.00 C,L,N,P,Q 12.06   YES YES
177.80(7") 20.00 H,J,K 6.91 YES
23.00 J,K,C,L,N 8.05 YES YES YES
26.00 J,K,C,L,N,P 9.19 YES YES YES
29.00 C,L,N,P 10.36   YES YES
32.00 C,L,N,P 11.51   YES YES
35.00 C,L,N,P,Q 12.65   YES YES
38.00 C,L,N,P,Q 13.72   YES YES
193.68(7 5/8") 24.00 H 7.62 YES
26.40 J,K,C,L,N 8.33 YES YES YES
29.70 C,L,N,P 9.52   YES YES
33.70 C,L,N,P 10.92   YES YES
39.00 C,L,N,P,Q 12.70   YES YES
42.80 C,L,N,P,Q 14.27   YES YES
45.30 C,L,N,P,Q 15.11   YES YES
47.10 C,L,N,P,Q 15.88   YES YES
196.85(7 3/4") 46.10 C,L,N,P,Q 15.11
219.08(8 5/8") 24.00 J,K 6.71 YES
28.00 H 7.72 YES
32.00 H,J,K 8.94 YES YES YES
36.00 J,K,C,L,N 10.16 YES YES YES
40.00 C,L,N,P 11.43   YES YES
44.00 C,L,N,P 12.70   YES YES
49.00 C,L,N,P,Q 14.15   YES YES
244.48(9 5/8") 32.30 H 7.92 YES
36.00 H,J,K 8.94 YES YES YES
40.00 J,K,C,L,N 10.03   YES YES
43.50 C,L,N,P 11.05   YES YES
47.00 C,L,N,P,Q 11.99   YES YES
53.50 C,L,N,P,Q 13.84   YES YES
273.05(10 3/4") 32.75 H 7.09 YES
40.50 H,J,K 8.89 YES   YES
45.50 J,K 10.16 YES   YES
51.00 J,K,C,L,N,P 11.43 YES   YES
55.50 C,L,N,P 12.57 YES   YES
60.70 P,Q 13.84 YES   YES
65.70 P,Q 15.11 YES   YES
298.45(11 3/4") 42.00 H 8.46 YES
47.00 J,K,M 9.53 YES   YES
54.00 J,K,M 11.05 YES   YES
60.00 J,K,M,L,N,C,P,Q 12.42 YES   YES
339.7(13 3/8") 48.00 H 8.38 YES
54.50 J,K 9.65 YES   YES
61.00 J,K 10.92 YES   YES
68.00 J,K,C,L,N,P 12.19 YES   YES
72.00 C,L,N,P,Q 13.06 YES   YES
406.40(16") 65.00 H 9.53 YES
75.00 J,K,M 11.13 YES   YES
84.00 J,K,M 12.57 YES   YES
473.08(18 5/8") 87.50 H,J,K,M 11.05 YES YES YES
508.00(20") 94.00 H,J,K 11.13 YES YES YES
106.50 J,K 12.70 YES YES YES
133.00 J,K 16.13 YES YES YES
