Limestone Quarry Plant

One of the Top 500 enterprises in China foreign trade

QCCO was approved as a member of “China Association for Contracting Projects Abroad “and granted a membership certificate on Sep 28,2005; “Credibility Rating AAA certificate in Foreign Trade” was granted to QCCO by China Shippers’ Association



1 (5).jpg

Carbon steel pipe



1.seamless carbon steel pipe
2.Outer diameter:1/2"-24"
3.Wall thickness:SCH5S-XXS
4.API,ISO



carbon steel pipe



API 5L, ASTM A53 Gr.B ,erw welded carbon steel pipe

1. STANDARD: API 5L,API 5CT, ASTM A53B
2. MATERIAL: GrB, X42 ,X46  X52 X52  X60 X65 X70; J55; S235,S355

TYPE

CARBON steel pipe

Standard

API 5L,API 5CT,
ASTM A53B, ASTM A252, ASTM A36, ASTM A500.
DIN2458,EN10210

Matetial

GrB,Q235B, Q345;
X42 ,X46,X52,X56 X60 X65 X70;
H40.J55,K55; ASTM A500 a,b;
st37- st52; S235,S355

Size

1"-48”  (33.4mm-1220mm)

Wall thickness

sch10,sch20,sch30,sch40,STD,sch60, XS,sch80,

sch100,sch140,sch160,XXS

Packaging

Black painting, in Bundle or bulk, Container by sea .

Applications range

Petroleum, chemical, power; (oil,gas,water) liquid transport;
shipbuilding, construction, steel structure;  city piping system etc.



Outside Diameter Wall Thickness Outside Diameter Wall Thickness
21mm-630mm 1mm-50mm 1/2 to 16 inch STD;XS;XXS;SCH40;SCH80
Item Chinese Standard American Standard German Standard
1) 10# A53A St37
A106A St37-2 DIN17175
A179C St35.8 DIN1629
2) 20# ASTMA106-B St45-8 DIN17175
ASTMA53-B St42-2 DIN1626
ASTMA178-C St45-4 DIN1629
3) 45# ASTMA1045 CK45
Technique Cold drawn;
Hot rolled



 Spiral Carbon Steel Pipe   Carbon Steel Pipe





 Carbon Steel Pipe  Seamless Carbon Pipe

 Carbon steel pipe

Specifications

Steel Grade

Standard

seamless steel tubes

and pipes

for structural purpose

10, 20, 35, 45, 40Mn2, 45Mn2, 27SiMn, 20Cr, 40Cr, 20CrMo, 35CrMo, 38CrMoA1, 50CrV, 30CrMnSi

ASTM A500-98
ASTM A501-98
ASTN A519-98
JIS G3441-1994
JIS G3444-1994

Seamless steel tubes and pipes for

liquid service

10, 20, Q295, Q345

ASTM A53-98
ASTM A192
ASME S192
JIS G3452-1998
FIS G3454-1998
DIN 1629-1984

seamless steel tubes

and pipesfor casing

J55, N80

API

Seamless steel tubes for

oil casing and

tubing in oil wells

A, B, X42

API

Seamles Steel Tubes

and Pipes for

High Pressure Boiler

20G, 20MnG, 25MnG, 15MoG, 20MoG, 12Cr1MoVG, 15CrMoVG, 12Cr2MoG, 12Cr2MoWVTiB, 12Cr3MoVSiTiB,

ASTM A106-96a
ATSM A213-95a
JIS G3461-1988
JIS G3462-1998
DIN 17175-1979
BS3059Part 21990

Seamless Steel Tubes

for low and Medium Pressure Boilers

10, 20

ASTM A179, ASTM A192
ASTM SA179,SA192,
BS3059

Seamless Steel Tubes

 for high pressure --Chemical fertilizer equipment

10, 20G, Q345, Q390, 10MoVNb, 12CrMo, 15CrMo, 12Cr2Mo

ISO 9329-2-1997
ASTM A161-94

Seamless steel tubes

for petroleum cracking

10, 20, 12CrMo, 15CrMo, 1Cr2Mo, 1Cr5Mo,

JIS G3441-1988







(1)From 3/4"-3", our pipes are cold drawning.
(2)From 4"-12",our pipes are hot rolling.
(3)Over 12", our pipes are hot expansion.





A53 Chemical components and mechanical propert

stand
ard
Trade mark Chemical components   Mechanical property
C Si Mn P S Cu Ni Mo Cr V Tensile Strengt
h(Mpa)
Yield Streng
th(Mpa)
Elong
ation(
%)
ASTM A53 A ≤0.25 / ≤0.95 ≤0.05 ≤0.06 ≤0.40 ≤0.40 ≤0.15 ≤0.40 ≤0.08 ≥330 ≥205 ≥29.5
B ≤0.30 / ≤1.2 ≤0.05 ≤0.06 ≤0.40 ≤0.40 ≤0.15 ≤0.40 ≤0.08 ≥415 ≥240 ≥29.5





A106 Chemical components and mechanical property

stand
ard
Trade mark Chemical components   Mechanical property
C Si Mn P S Cu Ni Mo Cr V Tensile Strengt
h(Mpa)
Yield Stren
gth
(Mpa)
Elon
gation
(%)
ASTM
A106
 B ≤0.30 ≥0.10 0.29~
1.06
≤0.035 ≤0.035 ≤0.40 ≤0.40 ≤0.15 ≤0.40 ≤0.08 ≥415 ≥240 ≥30
 C ≤0.35 ≥0.10 0.29~
1.06
≤0.035 ≤0.035 ≤0.40 ≤0.40 ≤0.15 ≤0.40 ≤0.08 ≥485 ≥275 ≥30



API 5L Chemical components and mechanical property PSL1

Class and Sort Chemical components Mechanical property
 C
(Max)
 Mn
(Max)
 P
(Max)
 S
(Max)
  Tensile Strength( Min) Yeild Strengh(Min)
   psi  Mpa  psi  Mpa
A25 CLⅠ 0.21 0.6 0.03 0.03   45000 310 25000 172
CLⅡ 0.21 0.6 0.03 0.03
A 0.22 0.9 0.03 0.03   48000 331 30000 207
B 0.28 1.2 0.03 0.03   60000 414 35000 214
X42 0.28 1.3 0.03 0.03   60000 414 42000 290
X46 0.28 1.4 0.03 0.03   63000 434 46000 317
X52 0.28 1.4 0.03 0.03   66000 455 52000 359
X56 0.28 1.4 0.03 0.03   71000 490 56000 386
X60 0.28 1.4 0.03 0.03   75000 517 60000 414
X65 0.28 1.4 0.03 0.03   77000 531 65000 448
X70 0.28 1.4 0.03 0.03   82000 565 70000 483


A192 Chemical components and mechanical property

    Chemical components     Mechanical property
stand
ard
Trade mark C Si Mn P S Cu Ni Mo     Tensile Strengt
h(Mpa)
Yield Stren
gth
(Mpa)
Elong
ation
(%)
ASTM A192 A192 0.06-
0.18
≤0.25 0.27-0.63 0.035 0.035 / / /     ≥325 ≥180 ≥35



 1.JPG     1 (13).jpg





Carbon steel pipe Features and Benefits :

Material:Carbon steel pipe

Tolerance: meet the standard.

Standard:
ASTMA106Gr.B,;ASTMA53GR.B,APISPEC5LGR.B,BS1387,ASTMA179,ASTMA192,CA335,ASTMA333,DIN1629,ASTM A500-98,ASTM A500-98,ASTM A501-9JIS G3444-19948,ASTN A519-98,JISG3441-1994,ASTMA53-98,ASTMA192,ASTMES192,JISG3452

Application:The products are widely used in fertilizer, petroleum, centra-station, boiler, power station, shiping military, chemical industry, environment protection, traffic, food industry, medical equipement and so on.
Payment: T/T and L/C or negotiation
