508-2800mm PE Carbon Steel Pipe


 1. Product describe

Outer Diameter: 21.3mm-630mm
Well Thickness: 1.8mm-22.2mm
Our All Materials Grade:
ASTM A53: Gr. A B, Alloy steel pipe|Carbon steel pipe|spiral steel pipe|Galvanized steel
API A, B, J55, K55, X42, X46, X52, X56, X60 X65, X70 X80
GB/T3091, 9711: Q195, Q215, Q235, Q345, etc.
EN10217: P195TR1, P195TR2, P235TR1, P235TR2, P265TR1, P265TR2, P195GH, P235GH, P265GH, 16Mo3
EN10219: S235JRH, S235J0H, S235J2H, S355J0H, S355J2H, S355K2H, S275JR
DIN17100: ST52-3 ST44-2 ST37-2 etc
 Thick wall steel pipe| Drill pipe|welding steel pipe| Steel pipe |
Standard: EN10219
External Coating: 3PE
Production Capacity: 200, 000 tons/year
Application: Petroleum. Natural gas, coal gas distribution, tubing and
Casing, construction, heating, power, piles field. ERW steel pipe|pipe|Stainless steel pipeSeamless steel pipe |
Item Details  of   DIN17100   welded steel  pipe
Outer  Diameter 1-24   inch
Wall  Thickness 1.8mm----22.2mm
Length 5m-----16   m   Standard & Cut Length
Usage Line  Pipe, Casing  And  Tubing, Fluid  Pipe, Water  Delievery,
Heating  Pipe, Power  Pipe, Structure  Pipe, Scaffold, Piling  Pipe
Seamless steel pipe|API steel pipe|Manufacture  Processes Raw  material  Test→ Uncoiling→ Strip  leveling  → End  Cutting→   End  Shearing  and  Welding→ Accumlator→ Forming→ Telepathy  Welding → Seam  Heat  Treatment→ Air/Water  Cooling→ Body/Seam  UT→   Sizing  Straightening→ Cutting→ Visual  and  Dimension  Inspection→   Hydraulic  Test→ End  Beveling→ Flatten  Test→ Seam/End  UT→   Length-Measuring  and  Weighing→ Coating-Marking→ Storage
Ends  Processing Bevelled  or  Plain  End
Surface  Process 1  Oiled
2  Galvanized
3  3PE  Anti-corruption  coated
4  According  to  the  sustomers'   requirement
Test  Equipment
Raw  Material  Test Tensile  Test  , Yeild  Strength, Elogation, Impact  Test,
Chemical  Analysis, Hardness  Test, Charpy  Impact  Test,
Metallographic  Examination
Final  Product  Test Hydraulic  Test,   On-line  and  off-line  Ultrasonic  Test, Tensile  Test  ,
Yeild  Strength, Elogation, Hardness  Test, Charpy  Impact  , Flattening
Test Chemical  Analysis, Metallographic  Examination
Package 1  Naked
2  Both  ends  with  a  plastic  cap  , then  put  the  pipe  into  a  bundle covered  by  plastic         cloth  accroding  to  the  size  of  the  pipe  with  steel  belt  tied
3  According  to  the  sustomers'   requirement
Main  Market

Middle  East,   South  and  North  America,   Europe,   Asia, Oceania.   Southeast  Asia
