ASTM A53 ERW Black Pipe

ASTM A53 ERW Black Steel Pipes

1 Standard: BS,GB,ASTM,API 5L
2 Material:10# - 45#, Q195 - Q345
3 O.D: 219-1820mm

ASTM A53 ERW Black Steel Pipes1 Standard: BS,GB,ASTM,API 5L
2 Material :10# - 45#, Q195 - Q345
3 O.D : 5 - 20 mm,T.W : 219 - 1820mm

Product varieties, specification(Circular Pipe List)

outer diameter
(mm)

Theoretical Weight(kg)
Wallthickness(mm)
1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0 5.5 6.0 6.5 7.0 7.5 8.0 8.5
26.9 0.64 0.94 1.23 1.50 1.77
33.7 0.81 1.19 1.56 1.92 2.27 2.61 2.93
42.4 1.02 1.51 1.99 2.46 2.92 3.36 3.79
48.3 1.17 1.73 2.28 2.82 3.35 3.87 4.37 4.86
60.3   2.18 2.88 3.56 4.24 4.90 5.55 6.19 6.82 7.43
73     3.50 4.35 5.18 6.00 6.81 7.60 8.39 9.16 9.91
76     3.65 4.53 5.40 6.26 7.10 7.93 8.75 9.56 10.36
88.9     4.29 5.33 6.36 7.37 8.38 9.37 10.35 11.31 12.27 13.21
95     4.59 5.70 6.81 7.90 8.98 10.04 11.10 12.14 13.17 14.19
101.6     4.91 6.11 7.29 8.47 9.63 10.78 11.91 13.03 14.15 15.24 16.33
108       6.50 7.77 9.02 10.26 11.49 12.70 13.90 15.09 16.27 17.44
114.3       6.89 8.23 9.56 10.88 12.19 13.48 14.76 16.03 17.28 18.52 19.75
127       7.68 9.17 10.66 12.13 13.59 15.04 16.18 17.90 19.32 20.72 22.10
133         9.62 11.18 12.73 14.26 15.78 17.29 18.79 20.28 21.75 23.21 24.66
139.7         10.11 11.76 13.39 15.00 16.61 18.20 19.78 21.35 22.91 24.45 25.98
159           13.42 15.29 17.15 18.99 20.82 22.64 24.45 26.24 28.02 29.79
165.1           13.95 15.89 17.82 19.74 21.65 23.54 25.42 27.29 29.15 30.99 32.83
168.3           14.22 16.21 18.18 20.14 22.08 24.02 25.94 27.85 29.74 31.63 33.50
177.8             17.14 19.23 21.31 23.37 25.42 27.46 29.49 31.50 33.50 35.49
193.7             18.71 21.00 23.27 25.53 27.77 30.01 32.23 34.44 36.64 38.82
219.1             21.22 23.82 26.40 28.97 31.53 34.08 36.62 39.14 41.65 44.15



ERW PIPE,ASTM A53 ERW Black Pipe

Boiler Pipe,ERW Black Pipe
