stainless steel tube QX-003
Specifications
|
Name |
Stainless Steel Tube |
|||||
|
Items |
Square pipes, round tubes, oval pipes, special shaped pipes, empaistic pipes, fittings |
|||||
|
Standard |
ASTM A554, A249, A269 and A270 |
|||||
|
Material GradeSteel pipe | |
201: Ni 0.8%~1% |
|||||
|
202: Ni 3.5%~4.5%Drill pipe| |
||||||
|
304: Ni 8%, Cr 18% |
||||||
|
316: Ni 10%, Cr 18% |
||||||
|
316L: Ni10%~14% |
||||||
|
430: Cr16%~18%Steel pipe |
||||||
|
Outer Diameter |
6mm--169mm |
|||||
|
Thickness |
0.3mm - 3.0mm |
|||||
|
LengthCarbon steel pipe| |
6m or as customers' request |
|||||
|
Tolerance |
a) Outer Diameter: +/- 0.2mm |
|||||
|
b) Thickness: +/- 0.02mm |
||||||
|
c) Length: +/- 5mm |
||||||
|
Surface |
180G, 320G, 400G Satin / Hairline 400G, 500G, 600G or 800G Mirror finishSeamless steel pipe| |
|||||
|
Application |
Sanitary, food industry, Decoration, construction, upholstery, industry instrument welding steel pipe| |
|||||
|
Test |
Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT |
|||||
|
Chemical Composition of Material |
Material
Composition |
201 |
202 |
304 |
316 |
430 |
|
C |
≤0.15 |
≤0.15 |
≤0.08 |
≤0.08 |
≤0.12 |
|
|
Si |
≤1.00 |
≤1.00 |
≤1.00 |
≤1.00 |
≤1.00 |
|
|
Mn |
5.5-7.5 |
7.5-10 |
≤2.00 |
≤2.00 |
≤1.00 |
|
|
P |
≤0.06 |
≤0.06 |
≤0.045 |
≤0.045 |
≤0.040 |
|
|
S |
≤0.03 |
≤0.03 |
≤0.030 |
≤0.030 |
≤0.030 |
|
|
Cr |
16-18 |
17-19 |
18-20 |
16-18 |
16-18 |
|
|
N |
3.5-5.5 |
4-6 |
8-10.5 |
10-14 |
|
|
|
Mo |
|
|
|
2.0-3.0 |
|
|
|
Mechanical Property |
Material Item |
201 |
202 |
304 |
316 |
|
|
Tensile Strength |
≥535 |
≥520 |
≥520 |
≥520 |
||
|
Yield Strength |
≥245 |
≥205 |
≥205 |
≥205 |
||
|
Extension |
≥30% |
≥30% |
≥35% |
≥35% |
||
|
Hardness (HV) |
<253 |
<253 |
<200 |
<200 |
||
