One of the Top 500 enterprises in China foreign trade
QCCO was approved as a member of “China Association for Contracting Projects Abroad “and granted a membership certificate on Sep 28,2005; “Credibility Rating AAA certificate in Foreign Trade” was granted to QCCO by China Shippers’ Association
| Hot Finished Seamless Mechanical Steel Pipe. 50.8mm - 193.7mm | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Hot Finished Seamless Mechanical Steel Pipe EN 10297-1
|
|||||||||||
| O.D. mm | W T mm | O.D. mm | W T mm | O.D. mm | W T mm | O.D. mm | W T mm | O.D. mm | W T mm | O.D. mm | W T mm |
| 50.8 | 4.0 | 76.1 | 4.5 | 95.2 | 6.3 | 120.6 | 8.0 | 146.0 | 9.5 | 168.3 | 4.5 |
| 50.8 | 6.3 | 76.1 | 5.6 | 95.2 | 9.5 | 120.6 | 9.5 | 146.0 | 12.5 | 168.3 | 5.0 |
| 50.8 | 8.0 | 76.1 | 6.3 | 95.2 | 12.5 | 120.6 | 12.5 | 168.3 | 5.6 | ||
| 50.8 | 9.5 | 76.1 | 8.0 | 95.2 | 16.0 | 120.6 | 19.0 | 152.4 | 6.3 | 168.3 | 6.3 |
| 50.8 | 12.5 | 76.1 | 9.5 | 95.2 | 19.0 | 120.6 | 25.4 | 152.4 | 9.5 | 168.3 | 8.0 |
| 76.1 | 12.5 | 120.6 | 32.0 | 152.4 | 11.1 | 168.3 | 9.5 | ||||
| 57.1 | 4.0 | 76.1 | 16.0 | 101.6 | 4.0 | 152.4 | 12.5 | 168.3 | 12.5 | ||
| 57.1 | 6.3 | 76.1 | 19.0 | 101.6 | 5.0 | 127.0 | 5.0 | 152.4 | 16.0 | 168.3 | 16.0 |
| 57.1 | 9.5 | 101.6 | 6.3 | 127.0 | 6.3 | 152.4 | 19.0 | 168.3 | 25.0 | ||
| 57.1 | 12.5 | 82.5 | 6.3 | 101.6 | 8.0 | 127.0 | 9.5 | 152.4 | 25.0 | 168.3 | 30.0 |
| 82.5 | 9.5 | 101.6 | 9.5 | 127.0 | 12.5 | 152.4 | 31.8 | 168.3 | 35.0 | ||
| 60.3 | 4.5 | 82.5 | 12.5 | 101.6 | 12.5 | 127.0 | 16.0 | 152.4 | 35.0 | 168.3 | 40.0 |
| 60.3 | 5.0 | 82.5 | 16.0 | 101.6 | 16.0 | 127.0 | 19.0 | 152.4 | 40.0 | 168.3 | 50.0 |
| 60.3 | 6.3 | 82.5 | 19.0 | 101.6 | 19.0 | 127.0 | 25.0 | 152.4 | 45.0 | ||
| 60.3 | 8.0 | 101.6 | 25.0 | 177.8 | 6.3 | ||||||
| 60.3 | 9.5 | 88.9 | 4.0 | 133.0 | 6.3 | 159.0 | 9.5 | 177.8 | 9.5 | ||
| 60.3 | 12.5 | 88.9 | 4.5 | 108.0 | 6.3 | 133.0 | 9.5 | 159.0 | 12.5 | 177.8 | 12.5 |
| 88.9 | 5.0 | 108.0 | 9.5 | 133.0 | 12.5 | 159.0 | 19.0 | 177.8 | 19.0 | ||
| 63.5 | 6.3 | 88.9 | 5.6 | 108.0 | 12.5 | 133.0 | 19.0 | 159.0 | 25.0 | 177.8 | 25.0 |
| 63.5 | 8.0 | 88.9 | 6.3 | 108.0 | 16.0 | 133.0 | 25.0 | 159.0 | 30.0 | 177.8 | 34.9 |
| 63.5 | 9.5 | 88.9 | 8.0 | 108.0 | 19.0 | 159.0 | 35.0 | 177.8 | 40.0 | ||
| 63.5 | 12.5 | 88.9 | 9.5 | 139.7 | 5.6 | 159.0 | 40.0 | 177.8 | 50.0 | ||
| 63.5 | 16.0 | 88.9 | 12.5 | 114.3 | 4.5 | 139.7 | 6.3 | 159.0 | 50.0 | ||
| 88.9 | 16.0 | 114.3 | 5.6 | 139.7 | 8.0 | 193.7 | 5.6 | ||||
| 69.9 | 6.3 | 88.9 | 19.0 | 114.3 | 6.3 | 139.7. | 9.5 | 165.1 | 6.3 | 193.7 | 6.3 |
| 69.9 | 9.5 | 114.3 | 8.0 | 139.7 | 12.5 | 165.1 | 31.8 | 193.7 | 8.0 | ||
| 69.9 | 12.5 | 114.3 | 9.5 | 139.7 | 19.0 | 165. 1 | 38.1 | 193.7 | 9.5 | ||
| 69.9 | 16.0 | 114.3 | 12.5 | 139.7 | 25.0 | 193.7 | 12.5 | ||||
| 114.3 | 16.0 | 139.7 | 30.0 | 193.7 | 16.0 | ||||||
| 114.3 | 19.0 | 1397 | 35.0 | 193.7 | 19.0 | ||||||
| 114.3 | 25.4 | 139.7 | 40.0 | 193.7 | 25.0 | ||||||
| 193.7 | 30.0 | ||||||||||
| 193.7 | 35.0 | ||||||||||
| 193.7 | 40.0 | ||||||||||
| 193.7 | 50.0 | ||||||||||
| Hot Finished Seamless Mechanical Steel Tube. 203.2mm - 660mm | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Hot Finished Seamless Mechanical Steel Tube EN 10297-1 | |||||||||||
| O.D. mm | W T mm | O.D. mm | W T mm | O.D. mm | W T mm | O.D. mm | W T mm | O.D. mm | W T mm | O.D. mm | W T mm |
| 203.2 | 6.3 | 260.0 | 60.0 | 311.0 | 12.5 | 368.3 | 30.0 | 431.8 | 76.2 | 546.0 | 30.0 |
| 203.2 | 9.5 | 260.0 | 70.0 | 311.0 | 25.0 | 368.3 | 35.0 | 445.0 | 20.0 | 546.0 | 40.0 |
| 203.2 | 12.5 | 260.0 | 80.0 | 311.0 | 38.1 | 368.3 | 40.0 | 445.0 | 25.0 | 546.0 | 50.0 |
| 203.2 | 19.0 | 260.0 | 90.0 | 311.0 | 50.8 | 368.3 | 45.0 | 445.0 | 30.0 | 546.0 | 60.0 |
| 203.2 | 25.0 | 311.0 | 57.2 | 368.3 | 50.0 | 445.0 | 35.0 | ||||
| 203.2 | 38.1 | 273.0 | 6.3 | 368.3 | 60.0 | 445.0 | 40.0 | 550.0 | 80.0 | ||
| 203.2 | 50.8 | 273.0 | 7.1 | 323.9 | 6.3 | 368.3 | 65.0 | 445.0 | 55.0 | ||
| 273.0 | 9.5 | 323.9 | 7.1 | 368.3 | 80.0 | 445.0 | 60.0 | 558.8 | 20.0 | ||
| 219.1 | 5.0 | 273.0 | 12.7 | 323.9 | 9.5 | 445.0 | 65.0 | 558.8 | 25.0 | ||
| 219.1 | 6.3 | 273.0 | 16.0 | 323.9 | 12.7 | 381.0 | 12.5 | 445.0 | 70.0 | 558.8 | 35.0 |
| 219.1 | 7.0 | 273.0 | 19.0 | 323.9 | 14.2 | 381.0 | 20.0 | 558.8 | 40.0 | ||
| 219.1 | 9.5 | 273.0 | 25.0 | 323.9 | 19.0 | 381.0 | 25.0 | 457.2 | 558.8 | 45.0 | |
| 219.1 | 12.5 | 273.0 | 34.9 | 323.9 | 25.0 | 381.0 | 38.1 | 457.2 | 12.7 | 558.8 | 50.0 |
| 219.1 | 19.0 | 273.0 | 41.2 | 323.9 | 28.6 | 381.0 | 50.0 | 457.2 | 19.1 | 558.8 | 60.0 |
| 219.1 | 25.0 | 273.0 | 50.0 | 323.9 | 31.8 | 381.0 | 63.5 | 457.2 | 25.0 | 558.8 | 70.0 |
| 219.1 | 35.0 | 273.0 | 60.0 | 323.9 | 35.0 | 381.0 | 76.2 | 457.2 | 35.0 | 558.8 | 85.0 |
| 219.1 | 40.0 | 273.0 | 85.0 | 323.9 | 41.2 | 457.2 | 40.0 | 558.8 | 110.0 | ||
| 219.1 | 45.0 | 323.9 | 47.6 | 394.0 | 28.0 | 457.2 | 50.0 | ||||
| 219.1 | 50.0 | 279.4 | 20.0 | 323.9 | 50.0 | 394.0 | 30.0 | 457.2 | 60.0 | 572.0 | 25.0 |
| 219.1 | 60.0 | 279.4 | 25.0 | 323.9 | 55.5 | 394.0 | 35.0 | 457 .2 | 76.1 | 572.0 | 35.0 |
| 279.4 | 28.6 | 323.9 | 63.5 | 394 0 | 40.0 | 457.2 | 85.0 | 572.0 | 40.0 | ||
| 228.6 | 6.3 | 279.4 | 35.0 | 323.9 | 75.0 | 394.0 | 45.0 | 457.2 | 90.0 | 572.0 | 50.0 |
| 228.6 | 9.5 | 279.4 | 38.1 | 323.9 | 90.0 | 394.0 | 50.0 | 572.0 | 70.0 | ||
| 228.6 | 12.5 | 279.4 | 50.8 | 394.0 | 100.0 | 470.0 | 25.0 | 572.0 | 80.0 | ||
| 228.6 | 19.0 | 279.4 | 57.2 | 330.2 | 25.4 | 470.0 | 30.0 | 572.0 | 85.0 | ||
| 228.6 | 25.0 | 330.2 | 50.8 | 406.4 | 9.5 | 470.0 | 35.0 | ||||
| 228.6 | 34.9 | 292.0 | 19.0 | 330.2 | 76.2 | 406.4 | 12.7 | 470.0 | 45.0 | 610.0 | 12.7 |
| 228.6 | 44.4 | 292.0 | 25.0 | 406.4 | 19.1 | 470.0 | 50.0 | 610.0 | 20.0 | ||
| 228.6 | 50.0 | 292.0 | 38.1 | 342.9 | 20.0 | 406.4 | 25.0 | 470.0 | 60.0 | 610.0 | 25.0 |
| 228.6 | 60.0 | 292.0 | 46.0 | 342.9 | 25.4 | 406.4 | 28.0 | 470.0 | 70.0 | 610.0 | 30.0 |
| 292.0 | 50.8 | 342.9 | 30.0 | 406.4 | 30.0 | 610.0 | 35.0 | ||||
| 241.0 | 50.0 | 292.0 | 57.0 | 342.9 | 38. 1 | 406.4 | 36.0 | 495.0 | 30.0 | 610.0 | 40.0 |
| 241.0 | 60.0 | 342.9 | 45.0 | 406.4 | 40.0 | 495.0 | 35.0 | 610.0 | 45.0 | ||
| 241.0 | 70.0 | 298.5 | 9.5 | 342.9 | 50.0 | 406.4 | 50.0 | 495.0 | 40.0 | 610.0 | 50.0 |
| 241.0 | 80.0 | 298.5 | 12.5 | 342.9 | 63.5 | 406.4 | 55.0 | 495.0 | 45.0 | 610.0 | 60.0 |
| 298.5 | 14.2 | 342.9 | 90.0 | 406.4 | 60.0 | 495.0 | 50.0 | 610.0 | 70.0 | ||
| 244.5 | 5.9 | 298.5 | 16.0 | 406.4 | 70.0 | 495.0 | 55.0 | 610.0 | 80.0 | ||
| 244.5 | 7.1 | 298.5 | 20.0 | 355.6 | 9.0 | 406.4 | 76.2 | 495.0 | 75.0 | 610.0 | 85.0 |
| 244.5 | 9.5 | 298.5 | 25.0 | 355.6 | 12.7 | 406.4 | 80.0 | 610.0 | 95.0 | ||
| 244.5 | 12.5 | 298.5 | 30.0 | 355.6 | 16.0 | 406.4 | 88.9 | 508.0 | 9.5 | 610.0 | 100.0 |
| 244.5 | 16.0 | 298.5 | 35.0 | 355.6 | 19.1 | 406.4 | 90.0 | 508.0 | 12.5 | 610.0 | 110.0 |
| 244.5 | 19.0 | 298.5 | 40.0 | 355.6 | 25.0 | 406.4 | 100.0 | 508.0 | 20.0 | ||
| 244.5 | 25.0 | 298.5 | 45.0 | 355.6 | 28.6 | 508.0 | 25.0 | 622.0 | 25.0 | ||
| 244.5 | 33.4 | 298.5 | 50.0 | 355.6 | 31.8 | 419.1 | 20.0 | 508.0 | 35.0 | 622.0 | 30.0 |
| 244.5 | 35.0 | 298.5 | 55.0 | 355.6 | 38.1 | 419.1 | 25.0 | 508.0 | 40.0 | 622.0 | 35.0 |
| 244.5 | 38.0 | 298.5 | 75.0 | 355.6 | 44.4 | 419.1 | 30.0 | 508.0 | 50.0 | 622.0 | 40.0 |
| 244.5 | 40.0 | 298.5 | 90.0 | 355.6 | 50.0 | 419.1 | 35.0 | 508.0 | 60.0 | 622.0 | 45.0 |
| 244.5 | 50.0 | 355.6 | 63.5 | 419.1 | 40.0 | 508.0 | 70.0 | 622.0 | 50.0 | ||
| 244.5 | 75.0 | 304.8 | 7.1 | 355.6 | 70.0 | 419.1 | 45.0 | 508.0 | 80.0 | 622.0 | 60.0 |
| 304.8 | 9.5 | 355.6 | 76.2 | 419.1 | 50.0 | 508.0 | 110.0 | 622.0 | 85.0 | ||
| 254.0 | 6.3 | 304.8 | 12.5 | 355.6 | 80.0 | 419.1 | 55.0 | 622.0 | 95.0 | ||
| 254.0 | 9.5 | 304.8 | 19.0 | 355.6 | 100.0 | 419.1 | 60.0 | 521.0 | 20.0 | 622.0 | 100.0 |
| 254.0 | 12.5 | 304.8 | 25.0 | 419.1 | 70.0 | 521.0 | 25.0 | 622.0 | 110.0 | ||
| 254.0 | 19.0 | 304.8 | 38.1 | 368.3 | 10.0 | 419.1 | 90.0 | 521.0 | 30.0 | ||
| 254.0 | 25.0 | 304.8 | 50.8 | 368.3 | 16.0 | 419.1 | 100.0 | 521.0 | 50.0 | 660.0 | 40.0 |
| 254.0 | 38.1 | 304.8 | 55.0 | 368.3 | 17.5 | 521.0 | 60.0 | 660.0 | 70.0 | ||
| 254.0 | 50.8 | 304.8 | 63.5 | 368.3 | 20.0 | 431.8 | 12.7 | 521.0 | 70.0 | 660.0 | 80.0 |
| 254.0 | 55.0 | 304.8 | 80.0 | 368.3 | 25.0 | 431.8 | 25.0 | 521.0 | 75.0 | 660.0 | 100.0 |
| 254.0 | 60.0 | 431.8 | 38.1 | 521.0 | 80.0 | ||||||
| 431.8 | 44.4 | 521.0 | 90.0 | ||||||||
| 431.8 | 50.8 | ||||||||||
| 431.8 | 63.5 | 546.0 | 20.0 | ||||||||
